4 Axis Mini Desktop Collaborative Robot Arm Lightweight Industrial Robotic Arm for Automation

The MG400 has an all-in-one design that effortlessly fits into a 190 mm x 190 mm space. It is highly portable and is ideal for flexible production.

  • Robot Axes:4
  • Payload:500 g (Max. 750 g)
  • Working Radius:440mm
  • Repeated positioning accuracy:±0.05 mm
  • Base Size:190 mm × 190 mm

USD 2169

Monthly Output50

contact shop

Product Description

The MG400 is an ultra compact desktop grade robotic arm with footprint smaller than a piece of A4 size paper. It is safe for human collaboration, easy to use, and quick to deploy, making it perfect to automate small batch flexible productions. With 750 g maximum payload, 440 mm maximum reach, drag-to-teach and collision detection features, MG400 is a cost effective option for smart automation tasks.

Specification Parameters

Category

Specification

Number of Axes

4

Payload

500 g (Max. 750 g)

Working Radius

440 mm

Repeatability

±0.05 mm

Range of Motion

J1

±160°

J2

-25° ~ 85°

J3

-25° ~ 105°

J4

±360°

Maximum Joint Speed

J1

300°/s

J2

300°/s

J3

300°/s

J4

300°/s

Power

100~240V AC, 50/60 Hz

Rated Voltage

48V

Power Consumption

150W

Communication Interface

TCP/IP, Modbus TCP

Installation

Desktop

Weight

8 kg

Base Size

190 mm × 190 mm

Environment

0° ~ 40° C


Product Display




Desktop Grade Compact

The MG400 has an all-in-one design that effortlessly fits into a 190 mm x 190 mm space. It is highly portable and is ideal for flexible production.






Industrial Grade Performance

The MG400 is equipped with a servo motor having a high-precision encoder, proprietary drive and controller, to achieve ±0.05 mm repeatability. Vibration suppression algorithm increases multi-joint motion stability time by 60% and reduces residual vibration by 70%.







Simplicity for Usability

With drag-to-teach, the MG400 is designed to be easy to use. The MG400 lowers the barrier of entry into automation and is favored by numerous small and medium enterprises.






Wide Array of Programming Options

In addition to drag-to-teach, the MG400 can also be programmed using Lua and graphical interface, suitable for developers of all levels.



Schematic Diagram

Application Cases

Quality Inspection

Assembly

Transporting

Packaging & Transportation

Company Information

Avatar Intelligent Equipment Co., Ltd. specializes in the R&D and supply of robotic productsand mobile solutions for robot platforms. Its core product line covers various robot applica-tion-related products such as wall-climbing robots, cleaning robots, grippers, and robotic arms.The company has built an integrated service system from R&D, quality inspection, productionto sales and after-sales service, providing customers with reliable intelligent equipment supportthrough independent technical strength.

FAQ

Q1. who are we?

A:We are based in Henan, China, start from 2012,sell to South America(40.00%),Southeast Asia(30.00%),Eastern Europe(20.00%),Western Europe(5.00%),Domestic Market(5.00%). There are total about 11-50 people in our office.

Q2. how can we guarantee quality?

A: Always a pre-production sample before mass production; Always final Inspection before shipment;

Q3.what can you buy from us?

A: Robot Application and parts products.

Q4. what services can we provide?

A: Accepted Delivery Terms: FOB,EXW; Accepted Payment Currency:USD; Accepted Payment Type: T/T,Western Union; Language Spoken:English,Chinese.

Q5. How does your factory do the quality control?

A:There is system to control the quantity from IQC to production process to OQC.
